| Technical Data | ||||
| Max Glass Size | 3600*2500mm（length*width） | |||
| Min Glass Size | 300*180mm（length*width） | |||
| Max Glass Thickness | ≤10mm | |||
| Equipment Specifications | 11700*6200*6800mm（length*width*height） | |||
| Floor Distance | 40mm/60mm | |||
| Power Supply | ≈33kW | |||
| Transport Speed | 1-25m/min | |||
| Elevator Speed | 1-60m/min | |||
? Minimal horizontal floor space with optimized vertical storage utilization
? Ultra-high resilience support pads prevent glass warping during extended storage
? Flexible rubber contact surfaces, reducing spontaneous breakage rate
? Rapid horizontal transfer and vertical lifting
? Computerized glass tracking, automated glass retrieval based on predefined matching rules with MES integration
? Servo-driven lift cart with high positioning accuracy
? Multiple sheets stored per tier
? HMI displays tier-specific glass specifications and associated order data
? Automatic roller cleaning function for each storage layer
